Rm1 Setpnts Menu
MENU ITEM
SOFTWARE
NAME
ITEM DESCRIPTION
ITEM RANGE
DEFAULT
VALUE
Room1 Unoccupied
Mode Minimum
Supply Flow
Unoc Min
Flow
The Unoc Min Flow item sets the minimum supply flow
for unoccupied mode.
0 to 10,000 CFM
NOTE
Unoc Min Flow
cannot be set
greater than the
Max Sup Flow
0 CFM
NOTE: Input3 must be configured to measure supply flow
for this item to be active.
Input4 or Input6 must be configured accept an
occupancy sensor for this item to be active.
The Cntrl Device item must be set to
SUPPLY/EXHAUST/TEMP for this item to be
active.
This item can be adjusted even if not active.
Room1 Minimum
Supply Output
Min Sup Pos
The Min Sup Pos item sets the minimum output signal to
the supply control device.
0 to 100%
NOTE
Min Sup Pos
cannot be set
greater than the
Max Sup Pos
0%
NOTE: The Cntrl Device item must be set to
SUPPLY/EXHAUST/TEMP for this item to be
active.
This item can be adjusted even if not active.
Room1 Maximum
Supply Output
Max Sup Pos
The Max Sup Pos item sets the minimum output signal to
the supply control device.
0 to 100%
NOTE
Max Sup Pos
cannot be set less
than the
Min Sup Pos
100%
NOTE: The Cntrl Device item must be set to
SUPPLY/EXHAUST/TEMP for this item to be
active.
This item can be adjusted even if not active.
Room1 Minimum
Exhaust Flow
Min Exh Flow
The Min Exh Flow item sets the minimum exhaust flow
rate for Room1.
0 to 10,000 CFM
NOTE
Min Exh Flow
cannot be set
greater than the
Max Exh Flow
0 CFM
NOTE: Input7 must be configured for an exhaust flow
measurement for this item to be active. This item
can be adjusted even if not active.
The Min Exh Flow item is only used when the
Ctrl Devices item is set to Exhaust.
