TTL Touch - Menu Indications: Main Menu; Menu 1: Info

17
TTL Air curtain systems - control and automation panel type Touch
9. Displays and general operating settings (cont.)
9.2 Menue indications
9.2.1 Menue 1 - info
OK
Cancel
ersion
inputs
outputs
IR sensor
ŵĂůĨƵŶĐƟŽŶƐ
1 2 3 4 5 6 7 8 9 10
1
2
no malfunctions
/info/malfunctions
1 Info menue 1 - malfunctions
informations to malfunctions at connected units
resp. adresses of actual internal connecting board (PCB)
1 Info menue 2 - inputs
listing of all relevant measured datas of input values
(air target / -actual; water target / -actual; opening rate valve;
outdoor sensor; selected IR)
OK
Cancel
controller air volume (VOL)
statistics
settings
controller air temperature (AIR)
info
1 2 3 4 5 6 7 8 9 10
1
2
Main
Main menue with menue points
selection of desired menue item and
 FRQÀUPDWLRQZLWKWRXFKÀHOGÅ2.´
 XVHWRXFKÀHOGÅ&DQFHO´WRFKDQJHLQWRRSHUDWLRQYLHZ
OK
Cancel
ersion
inputs
outputs
IR sensor
ŵĂůĨƵŶĐƟŽŶƐ
1 2 3 4 5 6 7 8 9 10
1
2
/info/inputs
sensor air : 33.8 C
sensor water: 45.7 C
opening valve : 40 %
outside sensor : 0.6 C
IR sensor : 19.7 C
air target : 20.0 C
water target : 45.0 C
OK
Cancel
ersion
inputs
outputs
IR sensor
ŵĂůĨƵŶĐƟŽŶƐ
1 2 3 4 5 6 7 8 9 10
1
2
/info/inputs
sensor air : 33.8 C
sensor water: 45.7 C
air volume : 65 %
outside sensor : 0.6 C
selected IP : 19.7 C
opening valve : 45 %
DDC door ___
1 Info menue 3 - outputs
listing of all control datas for output vaues
(air volume performance; heating power (opening valve;
signal impact for release by DDC, door, room thermostate)
OK
Cancel
ersion
inputs
outputs
IR sensor
ŵĂůĨƵŶĐƟŽŶƐ
1 2 3 4 5 6 7 8 9 10
1
2
/info/IR sensor/sensors
Infrared sensor : temp
external IR 1 : 12.0°C
external IR 2 : 0.0°C
external IR 3 : 0.0°C
external IR 4 : 0.0°C
selected IR : 0.0°C
1 Info menue 4 - IR sensor
listing of measuring datas of connected Infrared sensors
- IR1 - IR 4 IR sensors connected by BUS
(assignment see menue 3 - settings - signal assignment),
- selected IR is the measured value at dialed adress, if a
grouping of IR sensors is assigned to this adress (functionelly
group) will the average of group be displayed
