TTL Touch - Menu 3: Settings

19
TTL Air curtain systems - control and automation panel type Touch
9. Displays and general operating settings (cont.)
9.2.3 Menue 3 - settings
OK
Cancel
DDC release manual mode
follow-up time
intensity reheating
auto run after frost alert
signal assignment
1 2 3 4 5 6 7 8 9 10
1
2
/settings
3 Settings-main menue with 14 menue items
 VHOHFWLRQRIGHVLUHGPHQXHLWHPDQGFRQÀUPDWLRQ
 E\WRXFKÀHOGÅ2.
OK
Cancel
room sensor
automatic contact
room thermostate
fault dealing
DDC release
1
2 3
4
5 6 7 8 9 10
1
2
/settings/signal assignment
1
3
4
5 6 7 8
9 10
2
3 Settings menue 1 - submenue 1 - DDC release
assignment which adresse(s) shall be switched
via DDC-release
This assignments allows to create functionally groups, although
this units have equivalent adresses.
OK
Cancel
room sensor
automatic contact
room thermostate
fault dealing
DDC release
1 2 3 4 5 6 7 8 9 10
1
2
/settings/signal assignment
1 3 4
5 6 7 8
9 10
2
3 Settings menue 1 - submenue 2 - automatic contact
assignment which adresse(s) shall be switched
via door contacts
This assignments allows to create functionally groups, although
this units have equivalent adresses..
OK
Cancel
room sensor
automatic contact
room thermostate
fault dealing
DDC release
1 2 3 4 5 6 7 8 9 10
1
2
/settings/signal assignment
1 3 4
5 6 7 8
9 10
2
3 Settings menue 1 - submenue 3 - room thermostate
assignment which adresse(s) shall be switched
via room thermotate connected at internal conn. board
This assignments allows tp create functionally groups, although
this units have equivalent adresses.
OK
Cancel
fault dealing
room sensor
IR sensor
room thermostate
1
2 3
4
5 6 7 8 9 10
1
2
/settings/signal assignment
1
3
4
5 6 7 8
9 10
2
3 Settings menue 1 - submenue 4 - fault dealing
assignment which adresse(s) shall be switched
in case of faults, over this the swich-OFF behaviour can
determined in case of motor faults (all units of network,
determined units or only the faulty unit)
This assignments allows to create functionally groups, although
this units have equivalent adresses..
OK
Cancel
DDC release manual mode
follow-up time
intensity reheating
auto start after frost alert
signal assignment
1 2 3 4 5 6 7 8 9 10
1
2
/settings/signal assignment
3 Settings menue 1 - signal assignment
assignment of external signals like measured values of sensors,
door contacts, room thermostates to the several devices
of unit network, assigment of dealing in case of faults
