9. Displays and general operating settings (cont.)
9.2.3 Menue 3 - settings (cont.)
OK
Cancel
fault dealing
room sensor
IR sensor
room thermostate
1
2 3
4
5 6 7 8 9 10
1
2
/settings/signal assignment
1
3
4
5 6 7 8
9 10
2
3 Settings menue 1 - submenue 6 - IR sensor
assignment which sensor(s) 1 - 4 shall switch which
adress(es)
This assignments allows to create functionally groups, although
this units have equivalent adresses..
OK
Cancel
DDC release manual mode
follow-up time
intensity reheating
auto start after frost alert
signal assignment
1
2 3
4
5 6 7 8 9 10
1
2
0 sec
follow-up time
/settings/follow-up time
3 Settings menue 2 - follow-up time
setting of a follow-up time for overrun of unit after closing
door (switching of autoamtic contact) for HEATING mode
3 Settings menue 3 - intensity reheating
preselection which intensity of heating (opening rate of valve)
is used in HEATING mode (comp. menue item 6)
OK
Cancel
DDC release manual mode
follow-up time
intensity reheating
auto start after frost alert
signal assignment
1 2 3 4 5 6 7 8 9 10
1
2
80 % opening valve
follow-up time
/settings/intensity reheating
OK
Cancel
winter mode permission
auto start after frost alert
DDC release manual mode
ext. contact enables winter mode
intensity reheating
1 2 3 4 5 6 7 8 9 10
1
2
OFF
/settings/DDC release manual mode
DDC release
manual mode
3 Settings menue 5 - DDC release manual mode
preselection for necessary of DDC enable in HAND mode
3 Settings menue 4 - auto start after frost alert
 SUHVHOHFWLRQIRUVHOIDFWLQJRUFRQÀUPHGUHVWDUWDIWHUIURVW
alarm fault
OK
Cancel
winter mode permission
auto start after frost alert
DDC release manual mode
ext. contact enables winter mode
intensity reheating
1
2 3
4
5 6 7 8 9 10
1
2
OFF
/settings/auto start after frost alert
frost alert
selfreset
OK
Cancel
fault dealing
room sensor
IR sensor
room thermostate
1 2 3 4 5 6 7 8 9 10
1
2
/settings/signal assignment
1 3 4
5 6 7 8
9 10
2
3 Settings menue 1 - submenue 5 - room sensor
assignment which adresse(s) shall be switched
via room sensor
This assignments allows to create functionally groups, although
this units have equivalent adresses..
