TuffStuff AXT-2.5 - Step 4: Weight Stack Assembly; Step 4 Assembly List

Step 4
Step 4 Assembly List
Item # Description Qty.
13 CHROME GUIDE ROD 3/4 X 73 5/8 2
35 SELECTOR PIN W/COIL 3/8 X 4 1
43 TOP GUIDE ROD RETAINER 1
47 10 LB STEEL WEIGHT PLATE 4 9/16 X 9 7/16 19
48 10 LB TOP PLATE W/ADJ SLTR BAR 19 WTS 1
66 CHROME WASHER 3/8 X 1 1/2 2
77 DECAL-WEIGHT NUMBERS REF TP-10 (200 lbs) 1
88 FLAT WASHER SAE 3/8” 2
102 HEX HEAD CAP SCREW 3/8-16 X 3 2
106 HEX HEAD CAP SCREW 3/8-16 X 5 1
121 NYLON INSERT LOCK NUT 3/8-16 3
136 RUBBER DONUT 3/4 X 2 1/2 2
6 AXT-2.5 AXT- Cable Motion Plus Home Gym
121
106
