TuffStuff AXT-2.5 - Step 5: Press Bar Assembly; Step 5 Assembly List

106
88
42
41
88 121
131
5 66 151
65
32
66
151
65
28
149
149
147
147
31
7AXT-2.5 AXT- Cable Motion Plus Home Gym
Step 5
Step 5 Assembly List
Item # Description Qty.
28 PRESS BAR 1
32 PRESS BAR PIVOT AXLE 1 X 5 5/8 1
65 BUTTON HEAD SOC SCREW 3/8-16 X 1 2
66 CHROME WASHER 3/8 X 1 1/2 2
88 FLAT WASHER SAE 3/8” 2
106 HEX HEAD CAP SCREW 3/8-16 X 5 1
121 NYLON INSERT LOCK NUT 3/8-16 1
131 PLASTIC STOPPER 1
147 SOCKET HEAD CAP SCREW 1/4-28 X 3/4 4
149 SPLIT COLLAR 1” 2
151 SPLIT LOCK WASHER 3/8” 2
NOTE:
TWO PEOPLE ARE REQUIRED TO DO THIS STEP.
