10
Configuration Menu
The “Configuration Menu” is accessed after unlocking the Universal Senor and
contains a list of the options used to set up the Universal Sensor.
Select Mode: Used to select which
predefined sensor type the
Universal Sensor should
operate as.
Advanced Mode: Changes can be made here to
the Input type (RJ11 or
3.5mm) and the contact
channel (Normally Open or
Normally Closed).
Battery: Used to configure AP and ALB
and displays the status of the
user changeable battery.
Language: Displays a list of selectable
display languages which the
Universal Sensor can operate
in.
Send Message: Sends a test radio message
from the Universal Sensor.
This will raise an alarm on the
Tunstall device. Exits back to
the Configuration Menu.
Setup Summary: Displays the current
configuration of the Universal
Senor.
About: Displays the current installed
firmware.
Exit: Exits the Configuration Menu
and puts the Universal Sensor
into its configured mode.
