35
Smoke Detector
After unlocking the Universal Sensor and entering “Select Mode” navigate the menu
using the “Up Button” and or “Down Button”
When “Smoke Detector” is highlighted press the “Select Button”
The Universal Sensor will confirm it is now configured to be used
with a 3
rd
party device as a Smoke Detector Sensor.
Suggested Configuration: this can be changed using “Advanced Mode”.
Contact Type NC
Input Channel 1
Cable Connection RJ11
The Universal Sensor can now be connected to a Smoke Detector with a normally
closed relay (sold separately) and to the Tunstall Home unit. Tunstall recommends
completing a test call before leaving the property.
