Pendant
After unlocking the Universal Sensor and entering “Select Mode” navigate the menu
using the “Up Button” and or “Down Button”
When “Pendant” is highlighted press the “Select Button”
The Universal Sensor will confirm it is now configured to be used
with a 3
rd
party device as a Pendant.
Suggested Configuration: this can be changed using “Advanced Mode”.
Contact Type NO
Input Channel 2
Cable Connection 3.5mm Jack
The Universal Sensor can now be connected to a 3
rd
party device which is going to be
used as a pendant and the
Tunstall Home unit. Tunstall recommends completing a
test call before leaving the property.
