TurboChef i5 Service Manual

2 SPECIFICATIONS AND INSTALLATION
Single Phase
i5 US model (i5-9500-1)
Voltage: 208/240 VAC*
Frequency: 60 Hz
Current: 48 amps
Max Input: 9500/11500 watts
Plug: NEMA 6-50P
i5 UK model (i5-9500-2-UK)
Voltage: 230 VAC
Frequency: 50 Hz
Current: 48 amps
Max Input: 10000 watts
Plug: IEC 309, 3-pin
i5 BK model (i5-9500-6-BK)
Voltage: 220 VAC
Frequency: 60 Hz
Current: 48 amps
Max Input: 10000 watts
Plug: IEC 309, 3-pin
i5 LA model (i5-9500-7-LA)
Voltage: 220 VAC
Frequency: 60 Hz
Current: 48 amps
Max Input: 10000 watts
Plug: NEMA 6-50P
i5 JK model (i5-9500-8-JK) - 50 Hz
(i5-9500-10-JK) - 60 Hz
Voltage: 200 VAC
Frequency: 50 or 60 Hz
Current: 46 amps
Max Input: 9000 watts
Plug: PSE-marked, 3-blade
* North America models include a voltage sensor
which detects 208 or 240 VAC. The voltage
sensor does not compensate for lack-of or over-
voltage installations.
Multi Phase
i5 EW model (i5-9500-4-EW)
Voltage: 400 VAC
Frequency: 50 Hz
Current: 19 amps
Max Input: 10000 watts
Plug: IEC 309, 5-pin
i5 AU model (i5-9500-5-AU)
Voltage: 400 VAC
Frequency: 50 Hz
Current: 19 amps
Max Input: 10000 watts
Plug: Clipsal 5-pin
i5 KW model (i5-9500-12-KW)
Voltage: 400 VAC
Frequency: 60 Hz
Current: 19 amps
Max Input: 10000 watts
Plug: IEC 309, 5-pin
i5 ED model (i5-9500-3-ED)
Voltage: 230 VAC
Frequency: 50 Hz
Current: 28 amps
Max Input: 10000 watts
Plug: IEC 309, 4-pin
i5 SD model (i5-9500-13-SD)
Voltage: 230 VAC
Frequency: 60 Hz
Current: 28 amps
Max Input: 10000 watts
Plug: IEC 309, 4-pin
i5 JD model (i5-9500-9-JD) - 50 Hz
(i5-9500-11-JD) - 60 Hz
Voltage: 200 VAC
Frequency: 50 or 60 Hz
Current: 25 amps
Max Input: 10000 watts
Plug: PSE-marked, 4-blade
Electrical Specifications
TurboChef recommends a Type D circuit breaker for all installations outside the US.
