TurboChef i5 Service Manual

APPENDIX - REPLACING OVEN COMPONENTS
A-3
Figure
Reference #
Item Description Item Part Number Hardware Description Hardware Part Number(s)
1 Door Assembly* I5-9308 Screw, #8-32 x 3/8, PFH, 100 Deg, SS 102809 (qty 6)
2 Door Gasket I5-9309 None None
3 Door Handle I5-9253 Screw, 1/4-20 x .25 lg, Serrated Hex 102947 (qty 4)
4 Door Skin I5-9109 Screw, 6-32 x .38, PFH, 100 Deg, SS 101430 (qty 9)
5 Drain Pan I5-9252 None None
6 Filter, Air I5-9039 None None
7 Filter Bracket i5-9060
Screw, Sh Mtl #8 x 1/2, Serrated PHTRH
Plug, Knockout, 1/2”, Black
A) 101688 (qty 6)
B) 101191 (qty 1)
8 Hand Grip I5-9256 Screw, #8 X 1/2, Serrated, PHTRH, Black Oxide 101691 (qty 2)
9 Jetplate (Bottom) I5-9159 N/A Included with part
Replacing Items - No Cover Removal Required (Figures A-1, A-2)
DANGER: Before replacing any oven component, ensure the oven is removed from any power
source. Replacing a component while the oven is plugged in can result in serious injury or death.
CAUTION: Before removing/installing any component, make sure it is disconnected from the
wire harness (where applicable).
NOTE: Hardware listed is required for installing component to oven.
To Replace This... First Remove This...
Item Part Number
No Covers
(Page A-3)
No Covers-
Open Top
(Page A-5)
Top Cover
(Page A-7)
Left Side
Cover
(Page A-9)
Right Side
Cover
(Page A-11)
Items Obstructing
Access
Thermostat, Cooling Fans 102086

Thermostat, High-Limit 102075

Filter, Filter Bracket
Thermostat, Magnetron (Left)* 102070
 
Magnetron (Left)
Thermostat, Magnetron (Right)* 102070
 
Magnetron (Right)
Transformer, Filament NGC-3061-1

Transformer, High-Voltage NGC-3062-1

Vent Catalyst Foil Pack RWD-9191

Vent Tube Cover
Vent Tube Cover I5-9209

Heat Chnl Wldmt
Voltage Sensor 100783

Waveguide (Left)* I5-9330
 
Mag, FT/Diode
Bracket, Capacitor,
WG Gasket
Waveguide (Right)* I5-9330
 
Mag, FT/Diode
Bracket, Capacitor,
WG Gasket
Waveguide Gasket (Left)* I5-9331
 
Mag, FT/Diode
Bracket, Capacitor,
WG Gasket
Waveguide Gasket (Right)* I5-9331
 
Mag, FT/Diode
Bracket, Capacitor,
WG Gasket
Weldment, Heat Channel, Vent Tube NGC-1397

* See page A-12 through A-13 for removing door, hinge components, magnetrons, magnetron thermostats, or waveguides.
