A-1
APPENDIX - REPLACING OVEN COMPONENTS
To Replace This... First Remove This...
Item Part Number
No Covers
(Page A-3)
No Covers-
Open Top
(Page A-5)
Top Cover
(Page A-7)
Left Side
Cover
(Page A-9)
Right Side
Cover
(Page A-11)
Items Obstructing
Access
Blower Motor (Bottom) I5-9042
EMI Filter, EMI Fil Brkt
Blower Motor (Top) I5-9040
EMI Filter, EMI Fil Brkt
Blower Wheel (Bottom) 103550
Blower Motors
Blower Wheel (Top) 103551
Blower Motors
Capacitor, High-Voltage 100232
Capacitor Clamps
Capacitor Clamp 100134
Catalytic Converter I5-9066
RTD and Heater Assy
Control Board CON-7002
Cooling Fan (Exterior) TC3-0433
Filter, Filter Brkt, Finger
Guard
Cooling Fan (Interior) TC3-0433
Cooling Fan Finger Guard 100086
Filter, Filter Bracket
Cooling Fan, Magnetron 100083
Cooling Fan (Magnetron) Bracket I5-9263
Diodes, High-Voltage 100481
Display 103360
Door Assembly* I5-9308
Door Gasket I5-9309
Shunt Plate
Door Handle I5-9253
Door Skin
Door Skin I5-9109
Door
Drain Pan I5-9252
EMI Filter 100546
EMI Filter Bracket I5-9257
Filter, Air I5-9039
Filter Bracket I5-9060
Fuse, F1, 12-amp 100592
Fuse, F2, 12-amp 100592
Fuse, F3, 12-amp 100592
Fuse, F4, 12-amp 100592
Fuse Holder 103548
Fuses
Hand Grip I5-9256
Heat Shield/Support Bracket I5-9224
Heat Slinger 102708
Blower Motors
Heater Assembly I5-9284
RTD
Helper Spring, Interlock Switch (Left) 103599
Helper Spring, Interlock Switch (Right) 103599
Hinge, Bracket, Slide, LHS I5-9196
Door, Switches
Hinge, Bracket, Slide, RHS I5-9195
Door, Switches
Hinge, Cam, Weldment, LHS I5-9313
Door, Switches
Hinge, Cam, Weldment, RHS I5-9314
Door, Switches
Comprehensive Table of Oven Components
DANGER: Before replacing any oven component, ensure the oven is removed from any power
source. Replacing a component while the oven is plugged in can result in serious injury or death.
NOTE: For hardware, see the illustrations contained in this appendix.
* See page A-12 through A-13 for removing door, hinge components, magnetrons, magnetron thermostats, or waveguides.
