TurboChef i5 Service Manual

A-2
APPENDIX - REPLACING OVEN COMPONENTS
To Replace This... First Remove This...
Item Part Number
No Covers
(Page A-3)
No Covers-
Open Top
(Page A-5)
Top Cover
(Page A-7)
Left Side
Cover
(Page A-9)
Right Side
Cover
(Page A-11)
Items Obstructing
Access
Hinge, Guide, Switch Slide, Lower I5-9316
 
Door, Switches
Hinge, Guide, Switch Slide, Upper I5-9315
 
Door, Switches
Hinge, Gusset, LHS I5-9178
 
Door, Switches
Hinge, Gusset, RHS I5-9179
 
Door, Switches
Hinge Module, Base I5-9193
 
Door, Switches
Hinge, Torsion Bar I5-9144
 
Door, Switches
Hinge, Weldment, Countrblnce Bracket, LHS I5-9326
 
Door, Switches
Hinge, Weldment, Countrblnce Bracket, RHS I5-9327
 
Door, Switches
Interlock Switch (Monitor) 102012

Interlock Switch (Primary) 102012

Interlock Switch (Secondary) 102012

Jetplate (Bottom) I5-9159

Rack
Jetplate (Top) I5-9203

Keypad I5-9247

Lower Front Panel I5-9246

Drain Pan
Magnetron (Left)* NGC-3015
 
Magnetron (Right)* NGC-3015
 
Motor Controller 100446

Power Cord I5-9127

Power Supply 101211

Pwr Supply Brkt
Power Supply Bracket I5-9280

Rack I5-9168

Rack Support I5-9165

Rack
Relay (K1 - Filament) 101273

Relay (K2 - Anode) 101273

Relay (K3 - Monitor) 101273

Relay (K6 - Voltage) 101272

Relay (K7 - Mag Fan) 101273

Relay (K8 - Stirrer) 101273

Relay Bracket I5-9261

Relay, Solid State (K4/K5 - Heaters) 101286

RTD, Cook Cavity HHC-6517

Shunt Plate Assembly I5-9307

Door
Smart Card/USB Port CON-7005

Control Board
Speaker 104155

Stirrer I5-9154

Top Jetplate
Stirrer Hub 104132

Stirrer Motor
Stirrer Motor I5-9361

Stirrer Mtr Bracket
Stirrer Motor Bracket I5-9075

Stirrer Shaft I5-9151

Stir Mtr, Brkt, Top
Jetplate, Stirrer
Thermocouple, EC 700-1199

* See page A-12 through A-13 for removing door, hinge components, magnetrons, magnetron thermostats, or waveguides.
