OVEN SYSTEMS
25
Figure 26A: Properly Adjusted Door - Side Views
Oven Door
Oven Frame
Hinge
SM Switches
Remove
Bolts
Oven Door
Hinge
P Switch
Oven Frame
Figure 26B: Door Misaligned Variation 1 - Side Views
Tap in this
corner
Figure 26C: Door Misaligned Variation 2 - Side Views
Tap in this
corner
Remove
Bolts
First remove
switches, then
tap here
