A-6 APPENDIX - REPLACING OVEN COMPONENTS

Figure

Reference #

Item Description Item Part Number Hardware Description Hardware Part Number(s)

1 Cover, Top I5-9243 Screw, #10-32 x 3/8 lg, PFLH, 100 Deg, SS 101401 (qty 2)

2 Fuse, F1, 12-amp 100592 None None

3 Fuse, F2, 12-amp 100592 None None

4 Fuse, F3, 12-amp 100592 None None

5 Fuse, F4, 12-amp 100592 None None

6 Fuse Holder 103548 Screw, #8-32 x 3/8, PPHD, Int Sems, SS 102921 (qty 4)

7 Heat Shield/Support Bracket I5-9224 Screw, Torx Head, Sh Mtl, 3/8, Cres 102752 (qty 2)

8 Keypad* I5-9247 None None

9 Power Supply 101211 Screw, M3 x 8mm, Sems, PPHD, Cres 103444 (qty 3)

10 Power Supply Bracket I5-9280 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 2)

11 Relay (K1 - Filament) 101273 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)

12 Relay (K2 - Anode) 101273 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)

13 Relay (K3 - Monitor) 101273 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)

14 Relay (K6 - Voltage) 101272 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)

15 Relay (K7 - Mag Fan) 101273 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)

16 Relay (K8 - Stirrer) 101273 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)

17 Relay Bracket I5-9261 Screw, #8 x 3/8 PH Mod Truss, Cres 101682 (qty 4)

18 Relay, Solid State (K4/K5 - Heaters) 101286 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 2)

* NOTE: Additional keypad detail on Figure A-6, page A-8.
