61
SERVICE PARTS AND ILLUSTRATIONS
101
102
100
99
98
97
105
103
1
1
104
2
106
NOTICE:
This device complies with Part 18
of the FCC Rules.
Operation is subject to the followi
ng conditions:
1. This device may not cause harmful
interference.
WARNING:
DHHS Federal Performance Standard 2
1 CFR 1030.10.
To provide contin
ued protection aga
inst electrical
Pour assurer protection continue c
ontre le choc
shock, connect to
properly grounded outlets only.
AVERTISSEMENT
:
correctement mise
a terre.
electrique branchez seulement a une
prise
undesired operati
on.
2. This device mus
t accept any int
erference
received, includi
ng interference t
hat may cause
This Oven complies
with applicable sec
tions of
Convection Circuit Parts
97. 101688 Screw, #8 x 1/2” PTH
98. NGC-1081
Co
ver, Motor, Cap
99. 100905
Nut, 1/4”-20, Flange
100. NGC-1025 Assy, Blower Motor
101. 101688 Screw, #8 x 1/2” PTH
102. 100661 Heater, Convection
103. 100443 Controller, Motor
104.
101284
R
elay
, K4/K5 SSR
105. 100592 Buss, Fuses (12 Amp)
106.
102075
High-Limit Thermostat
FIGURE 32: CONVE
CTION CIRCUIT ASSEMBLY AND PARTS
Chapter 7: Convection Circuit - Page 42
