TurboChef NGC (Tornado)

62
SERVICE PARTS AND ILLUSTRATIONS
129
107
117
2X
AR
109
108
4X
AR
117
124
110
126
4X
128
127
111
122
4X
114
125
116
119
118
121
120
117
123
4X
AR
115
122
113
112
2X
1
SIDE VIEW
.20
Blower Motor Parts
107. 700-0306-2 Hub, Small
108. NGC-1019-2 Fan Blade, NGC Oven
109. NGC-1020 Ring, Fan Blade
110.
NGC-1021
P
late, B
lower Cap
111. 700-0284 Shim, Seal
112.
NGC-1024 Sealing Block Blower
113. 100443 Washer, Wave Spring,
30mmOD
114. NGC-1023 Clamp, Blower Seal
115. 102708
H
eat S
linger
, F
an, PM M
otor
116. 100882 Motor, 1HP, Flange Mount
Aspen
117. 100790
Loctite, #272
118. NGC-1022 Spacer, Blower Motor
119. 101393 Bolt, Hex, 1/4”-20 x 3/4” Lg,
CRES
120. 102400 Washer, Splitlock, 1/4”, CRES
121. 101392 Screw, PFLH, 1/4”-20 x 1/2” Lg,
100
º
, Cres
122.
102963
N
ut, H
ex, #10-32 E
xt
T
ooth
Keps, CRES
123. 102200 Washer, Flat, 1/4”, Cres
124.
102921
Scr
ew, #8-32 x 3/8” Int Tooth
Keps, CRES
125. 100730 Key, Woodruff, Steal
126. NGC-1122 Spacer, Blower, Insulation
127. NGC-1102 Heat Shield, Blower Motor
128. NGC-1123 Insulation, Blower Plate
129.
101711
S
et Scr
e
w
, Skt Hd
#10-32 x 5/16” CRES
FIGURE 33: BL
OWER MOTOR PARTS AND ASSEMBLY
Chapter 7: Convection Circuit - Page 43
