FEN20 Product Family
3 FEN20 Product Family
The common features and operating procedures, which are described in this guide, may be ap-
plied to every released FEN20 device, see the following table and „3.1 Definition of Terms“.
Article IP Input description Output description EtherNet/IP™™ Ad-
vanced
features
Address setup Number of inputs DIN rail mount Input type Signal type Short circuit protection Number of outputs Output type Signal type Maximum output load Short circuit protection Ethernet ports Conguration Assembly DLR QC ACD FLC BEEP
FEN20-4DIP-4DXP S 8 - DI PNP
✓
8 DO PNP 0.5A - 2
✓ ✓ ✓ ✓ ✓ ✓
FEN20-4DIP-4DXP-DIN S 8
✓
DI PNP - 8 DO PNP 0.5A
✓
2
✓ ✓ ✓ ✓ ✓ ✓
FEN20-4DIN-4DXN S 8 - DI NPN
✓
8 DO NPN 0.5A
✓
2
✓ ✓ ✓ ✓ ✓ ✓
FEN20-4DIN-4DXN-DIN S 8
✓
DI NPN
✓
8 DO NPN 0.5A
✓
2
✓ ✓ ✓ ✓ ✓ ✓
FEN20-EN1 S 8 - R PNP - - - - -
✓
2
✓ ✓ ✓ ✓
- -
FEN20-EN1-DIN S 8
✓
R PNP - - - - -
✓
2
✓ ✓ ✓ ✓
- -
FEN20-16DXP SH 16 - DI PNP - 16 DO PNP 0.5A
✓
2
✓ ✓ ✓ ✓
- -
3.1 Denition of Terms
■
Address setup
S Software setup
SH Software & Hardware setup via rotary switches
■
IO type
DI Discrete input
DO Discrete output
R Router function
AI Analog input
AO Analog output
■
Signal type
PNP Sourcing
NPN Sinking
■
EtherNet/IP™
ū
Configuration assembly – enables passing configuration data during ForwardOpen
ū
DLR Device Level Ring
ū
QC QuickConnect
ū
ADC Address Conflict Detection
■
Advanced features
ū
FLC Field Logic Controller
FEN20 can be converted into a simple Field Logic Controller (i.e. PLC) that can execute a
stand-alone application or become a distributed control component of the EtherNet/IP™,
