55
7. Remove the belt by sliding it between the pulley
and the frame as shown.
93
Installing the Main Drive Belt
8. Installthe new belt,C,and positionontheengine
pulley.
9. Position the engine belt guide, B, 1/4 inch from
the engine pulley and tighten bolt, A.
A
B
C
94
10. Install belt on the remaining pulleys as shown.
95
