998-2300 Rev. H Page 24
Appendix A: C3 Submersible Fluorometer Specifications
C3 Submersible Fluorometer
Weight in Air 1.64 kg (3.6 lbs)
Length 23 cm (9.1 in.)
Diameter 10 cm (3.9 in.)
Material Delrin
Temperature -2 to 50 °C
Temperature Accuracy 0.5 °C
Temperature Resolution 0.1
Depth 600 meters
External Power 8 to 30 VDC
Signal Output Digital (ASCII) or Analog (Note: analog requires accessory)
Interface RS232 (USB Adapter)
Maximum Sampling Rate 1 second
Nonvolatile Memory 64,000 Data Lines
Power Draw - Sleep Mode < 1mAmp
Power Draw - Max 1 Watt
Submersible Battery Pack
Battery Lithium-Ion
Weight in Air 0.75 kg (1.65 lbs)
Weight in Water 0.22 kg (0.50 lbs)
Length 13.46 cm (5.3 in.)
Diameter 7 cm (2.75 in.)
Material Delrin
Temperature -2 to 50 °C
Depth 600 meters
Capacity 2,200 mAH
Voltage Output 14.8V nominal
Protection Features
Protects against: overcharge, over-discharge, overheating,
short-circuiting
