Tuthill KINNEY KC Series User Manual

Manual 1807 Rev B p/n 001807 0000
4
01
Introduction
SPECIFICATIONS
MODEL KC-5 KC-8 KC-15
Free air displacement
5 CFM
(1.42 L/sec)
8 CFM
(3.78 L/sec)
15 CFM
(7.08 L/sec)
Pump speed 630 rpm 1,000 rpm 525 rpm
Motor
0.33 HP
(0.25 kW)
0.5 HP
(0.37 kW)
1.0 HP
(0.75 kW)
Oil capacity
0.5 qt
(0.47 L)
0.8 qt
(0.76 L)
3 qt
(2.84 L)
Inlet connection 1 in. FNPT 1 in. FNPT 2 in. FNPT
Discharge connection 3/4 in. FNPT 3/4 in. FNPT 1-1/4 in. FNPT
Pump shaft diameter
3/4 in.
(19.1 mm)
3/4 in.
(19.1 mm)
3/4 in.
(19.1 mm)
Approximate length
19.13 in.
(486 mm)
19.50 in.
(495 mm)
22.50
(572 mm)
Approximate width
13.25 in.
(337)
12.31 in.
(313 mm)
18.06
(459 mm)
Approximate height
16.19 in.
(411 mm)
16.19 in.
(411 mm)
25.75
(654 mm)
Approximate weight (complete assembly)
115 lb
(52 kg)
120 lb
(54 kg)
210 lb
(95 kg)
Table 1-1

Tuthill KINNEY KC Series Specifications
