33
09
Replacement Parts
Manual 1807 Rev B p/n 001807 0000
KC-8C Parts List
ITEM
NO.
DESCRIPTION
BRAKE
FLUID
SERVICE
QTY
REFRIGERATION/
MINERAL OIL QTY
1 CYLINDER 1 1
2 HEAD, OPEN END 1 1
3
HEAD, CLOSED
END
1 1
4
HOUSING, SHAFT
SEAL
1 1
5
FLANGE, SHAFT
SEAL SEAT
1 1
6 O-RING 1 1
7
CAP SCREW, HEX
HEAD
4 4
8 CAP, CLOSED END 1 1
9 COVER, CYLINDER 1 1
10
CAM, OPEN END
(HEAVY)
1 1
11 CAM, CLOSED END 1 1
12 PISTON 2 2
13 SLIDE PIN 2 2
14 SHAFT 1 1
15
DISCHARGE VALVE
KIT
1 1
16
BEARING &
SPACER SET
2 2
17
SIGHT GLASS
ASSEMBLY
1 1
18 GASKET 1 1
19 O-RING 2 2
20
SEAL, CENTER
WALL
1 1
ITEM
NO.
DESCRIPTION
BRAKE
FLUID
SERVICE
QTY
REFRIGERATION/
MINERAL OIL QTY
21 SHAFT SEAL 1 1
22 RETAINING RING 1 1
23 KEY, CAM 2 2
24 KEY, DRIVE SHAFT 1 1
25
DRAIN COCK W/
SEAL
2 2
26 GASKET 1 1
27
CAP SCREW, HEX
HEAD
1 1
28 DOWEL PIN 4 4
29
CAP SCREW, HEX
HEAD
37 37
30
OIL MIST
ELIMINATOR
1 1
30A ELEMENT 1 1
30B GASKET 1 1
30C SHEAVE 1 1
31 PIPE PLUG 1
32
GAS BALLAST
VALVE
1
33 ADAPTER 1
When ordering parts, use the item number shown,
plus the model and serial number.
For earlier production models or special application
pumps, consult factory for assistance.
