Replacement Parts
Manual 1807 Rev B p/n 001807 0000
KC-15D Parts List
ITEM
NO.
DESCRIPTION
BRAKE
FLUID
SERVICE
QTY
REFRIGERATION/
MINERAL OIL QTY
1 CYLINDER 1 1
2 HEAD, OPEN END 1 1
3
HEAD, CLOSED
END
1 1
4
HOUSING, SHAFT
SEAL
1 1
5 CAP, CLOSED END 1 1
6 COVER, CYLINDER 1 1
7
CAM, OPEN END
(HEAVY)
1 1
8 CAM, CLOSED END 1 1
9 PISTON 2 2
10 SLIDE PIN 2 2
11 SHAFT 1 1
12
DISCHARGE VALVE
KIT
1 1
13
CHAMBER, NOISE
ELIMINATION
1 1
14 BAFFLE, OIL 1 1
15A BALL BEARING 2 2
15B SPACER RING 2 2
16
SIGHT GLASS
ASSEMBLY W/
SCREWS
1 1
17 GASKET 1 1
18 O-RING 2 2
19
SEAL, CENTER
WALL
1 1
20
SHAFT SEAL
ASSEMBLY
1 1
21 RETAINING RING 2 2
22 KEY 2 2
23 KEY 1 1
24
GAS BALLAST
VALVE
— —
265
DRAIN COCK
(SPECIAL)
2 2
26 COUPLING 3 3
27 NIPPLE 2 2
28 NIPPLE — —
29 ELBOW 1 1
ITEM
NO.
DESCRIPTION
BRAKE
FLUID
SERVICE
QTY
REFRIGERATION/
MINERAL OIL QTY
30 PIPE PLUG 1 1
31 SEAL WASHER 1 1
32
CAP SCREW, HEX
HEAD
1 1
33 DOWEL PIN 6 4
34
CAP SCREW, HEX
HEAD
36 36
35
CAP SCREW, HEX
HEAD
20 20
36
CAP SCREW,
SOCKET HEAD
2 2
37 LOCK WASHER 2 2
38 MACHINE SCREW 2 2
39 LOCK WASHER 2 2
40
OIL MIST
ELIMINATOR
1 1
40A ELEMENT 1 1
40B GASKET 1 1
40C CHECK DISC 1 1
40D
CAP SCREW, HEX
HEAD
8 8
40E FLAT WASHER 8 8
41 SHEAVE 1 1
42
FLANGE, SHAFT
SEAL SEAT
1 1
43 O-RING 1 1
44
CAP SCREW, HEX
HEAD
4 4
45 RETAINING RING 1 1
46
BEARING BACKUP
RING
1 1
47
BEARING
CLAMPING DISC
1 1
48
CAP SCREW,
SOCKET HEAD
1 1
When ordering parts, use the item number shown,
plus the model and serial number.
For earlier production models or special application
pumps, consult factory for assistance.
