Tuthill KINNEY KC Series User Manual

37
09
Replacement Parts
Manual 1807 Rev B p/n 001807 0000
KC-15L Parts List
ITEM
NO.
DESCRIPTION
BRAKE
FLUID
SERVICE
QTY
REFRIGERATION/
MINERAL OIL QTY
10 CYLINDER 1 1
20 HEAD, OPEN END 1 1
30
HEAD, CLOSED
END
1 1
40
HOUSING, SHAFT
SEAL
1 1
50 CAP, CLOSED END 1 1
60 COVER, CYLINDER 1 1
70
CAM, OPEN END
(HEAVY)
1 1
80 CAM, CLOSED END 1 1
90 PISTON 2 2
100 SLIDE PIN 2 2
110 SHAFT 1 1
120
DISCHARGE VALVE
KIT
1 1
130
CHAMBER, NOISE
ELIMINATION
1 1
140 BAFFLE, OIL 1 1
150 BALL BEARING 2 2
160 SPACER RING 2 2
170
SIGHT GLASS
ASSEMBLY W/
1 1
180 GASKET 1 1
190 O-RING 2 2
200
SEAL, CENTER
WALL
1 1
210
SHAFT SEAL
ASSEMBLY
1 1
220 RETAINING RING 2 2
230 KEY 2 2
240 KEY 1 1
250
GAS BALLAST
VALVE
— —
260 DRAIN COCK 1 1
270
DRAIN COCK W/
O-RING
1 1
280 COUPLING 3 3
290 NIPPLE 2 2
300 NIPPLE 1 1
310 ELBOW 1 1
ITEM
NO.
DESCRIPTION
BRAKE
FLUID
SERVICE
QTY
REFRIGERATION/
MINERAL OIL QTY
320 PIPE PLUG 1 1
330 SEAL WASHER 1 1
340
CAP SCREW, HEX
HEAD
1 1
350 DOWEL PIN 6 4
360
CAP SCREW, HEX
HEAD
36 36
370
CAP SCREW, HEX
HEAD
20 20
380
CAP SCREW,
SOCKET HEAD
2 2
390 LOCK WASHER 2 2
400 MACHINE SCREW 2 2
410 LOCK WASHER 2 2
40
OIL MIST
ELIMINATOR
1 1
40A ELEMENT 1 1
40B GASKET 1 1
40C CHECK DISC 1 1
40D
CAP SCREW, HEX
HEAD
8 8
40E FLAT WASHER 8 8
41 SHEAVE 1 1
420
FLANGE, SHAFT
SEAL SEAT
1 1
430 O-RING 1 1
440
CAP SCREW, HEX
HEAD
4 4
450 RETAINING RING 1 1
460
BEARING BACKUP
RING
1 1
470
BEARING
CLAMPING DISC
1 1
480
CAP SCREW,
SOCKET HEAD
1 1
When ordering parts, use the item number shown,
plus the model and serial number.
For earlier production models or special application
pumps, consult factory for assistance.
