Replacement Parts
Manual 1807 Rev B p/n 001807 0000
KC-5 and KC-8 Parts List
ITEM NO. DESCRIPTION QTY
1 CYLINDER 1
2 HEAD, OPEN END 1
3 HEAD, CLOSED END 1
4 HOUSING, SHAFT SEAL 1
5 CAP, CLOSED END 1
6 COVER, CYLINDER 1
7 CAM, OPEN END (HEAVY) 1
8 CAM, CLOSED END 1
9 PISTON 2
10 SLIDE PIN 2
11 SHAFT 1
12 DISCHARGE VALVE KIT 1
13 BEARING & SPACER KIT 2
14 SIGHT GLASS ASSEMBLY 1
15 GASKET 1
16 O-RING 2
17 SEAL, CENTER WALL 1
ITEM NO. DESCRIPTION QTY
18 SHAFT SEAL 1
19 RETAINING RING 1
20 KEY 2
21 KEY 1
22 GAS BALLAST VALVE 1
23 DRAIN COCK W/ SEAL 2
24 GASKET 1
25 CAP SCREW, HEX HEAD 1
26 DOWEL PIN 6
27 CAP SCREW, HEX HEAD 41
When ordering parts, use the item number shown,
plus the model and serial number.
For earlier production models or special application
pumps, consult factory for assistance.
