Manual 2007 Rev B p/n 2007
52
Parts List
Parts List for Model 7000 Series – Internal Lube Double Mechanical Seals
ITEM
NO.
PART DESCRIPTION QTY
1 Rotor 2
3 Housing 1
4 End Plate 2
6 Drive End Cover 1
7 Free End Cover 1
8 Timing Gear Set 1
9 Bearing, Drive End 2
10 Bearing, Free End 1
10 Bearing 1
13 Lip Seal, Viton 1
14 Retainer 3
15 Retainer 1
20 Oil Slinger 1
22 Dowel Pin 8
23 Drive Shaft Key 1
24 Gear Key 2
25 Rotor Shaft Washer 3
26 Cap Screw 36
29 Bolt 3
30 Cap Screw 16
31 Magnetic Pipe Plug 1
42 Nameplate 1
45 Drive Shaft 1
50 Bearing 1
51 Lab Seal 4
54 Mechanical Seal 5
57 Rotor Spacer 1
59 Rotor Locking Tab 3
66 Cap Screw 4
67 Bearing Spacer 1
68 Dowel Pin 3
69 Cap Screw 4
74 Sealing Ring 4
75 O-Ring, Viton 5
ITEM
NO.
PART DESCRIPTION QTY
80 Lock Washer 4
89 Mechanical Seal Lock Ring 1
90 Set Screw 3
91 Nose Piece Lip Seal
Adapter
1
92 O-Ring, Viton 1
93 Cap Screw 4
101 St Elbow 1
102 Pipe Tube 1
106 Pipe Coupling 1
109 Pipe Plug 14 / 12
110 Cap Screw 3
121 Pipe Plug 4 / 10
122 Set Screw 2
124 Oil Filter, Spin On 1
125 Pump Mounting Bracket 1
135 Union, Tee, Tube 4
136 Lock Washer 4
144 Oil Pump 1
147 Tube, Al 1 / –
155 Tube Elbow 2
161 Tube, Al 2 / –
162 Tube, Al 1 / –
163 Tube Elbow 1
165 Tube Connector 1
172 Reducing Bushing 1
174 Pipe Plug 1
178 Tube Adapter 2
179 Tube, Al 1 / –
187 Tube 1
188 Tube Elbow, Union 4 / 2
195 Lifting Lug 2
196 Cap Screw 2
212 Cap Screw 2
226 Flat Washer 2
