Parts List
Parts List for Model 7000 Series – Internal Lube Double Mechanical Seals
(continued)
ITEM
NO.
PART DESCRIPTION QTY
235 Male Tube Adapter 5
236 Tube, Al 2 / –
262 Gauge, 30 Hg - 30 PIS,
Liquid Filled
1
265 Bypass Relief Valve 1
270 Oil Filter Adapter 1
271 Pipe Plug 2
294 Male Tube Adapter 1
300 Roll Pin 5
302 O-Ring, Viton 2
304 Mounting Foot 2
306 Sleeve 1
307 Cap Screw 4
322 Cap Screw 4
325 O-Ring, Viton 1
329 Plug 1
336 Orifi ce Fitting 5
337 Key 2
339 Plug 8
349 Pipe 1
350 Cap Screw 36
351 Pipe 4
354 Reducer Bushing 5
355 Tube, Al 1 / –
360 Oil Filter Threaded Tube 1
369 Tube 1
395 Oil Slinger 2
446 Oil Pump Cover 1
449 Rotor Sprocket Adapter 1
450A Chain, Roller 1
450B Chain Link Connector,
No. 35
1
451 Sprocket, No. 35 1
452 Sprocket, No. 35 1
ITEM
NO.
PART DESCRIPTION QTY
458 Pump Housing 1
459 Oil Gauge, Bullseye 1
479 Tube, Al – / 1
NOTES:
• QUANTITIES SHOWN ARE MAXIMUM
VALUES. QUANTITIES MAY VARY BETWEEN
BLOWER.
PARTS KITS ARE AVAILABLE. CONSULT
AUTHORIZED REPRESENTATIVE FOR PART
NUMBERS.
