TVC Ethos Two - Page 75

Page 75 of 102
TVL 351
ISSUE 15
ROTATING
AUTOTUNE
STATIONARY
AUTOTUNE
END END
Read precautions Read precautions
Check / set motor
parameters
(see overleaf)
Disconnect brake
Check / set motor
parameters
(see overleaf)
Set Parameter #B11
(Autotune)
to 2 (Rotating)
Set Parameter #B11
(Autotune)
to 1 (Stationary)
Enter and hold Test
direction
Enter and hold Test
direction
AUTOTUNE
Motor turns at 2/3
speed for 40
seconds
AUTOTUNE
Motor noise
heard for approx
3-5 seconds
Successful? Successful?
Set Parameter
#B16 to maximum
Resolve problem Resolve problem
No
[Error]
Yes [Parameter #B11 = 0] Yes [Parameter #B11 = 0]
No
[Error]
AUTOTUNE (CLOSED-LOOP, GEARED)
Reconnect brake
Set Parameter
#B16 to maximum
Carry out
Rotation Check
Save parameters
Save parameters
AUTOTUNE RESULTS
Stator Resistance
(#B34)
Transient Inductance
(#B33)
Current Limits
(#B16)
PRECAUTIONS - ROTATING AUTOTUNE
1. These instructions should be read in their
entirety before proceeding.
2. It is the responsibility of the competent
person to take all precautions as required when
conducting the following.
3. It is important that the lift car is prevented
from moving whilst an auto tune is being
conducted and that the motor shaft can revolve
freely. This normally implies that the motor be
disconnected from the gearbox where fitted or
that the lift is adequately secured in the well so
as to prevent movement and the ropes lifted
from the drive sheave, and additionally that the
brake is lifted.
4. Ensure that if the motor is disconnected from
the gearbox, then the motor shaft key is
secured or removed, as the motor rotates
during autotuning.
5. Ensure that no fault condition is present.
PRECAUTIONS - STATIONARY AUTOTUNE
1. These instructions should be read in their
entirety before proceeding.
2. It is the responsibility of the competent
person to take all precautions as required when
conducting the following.
3. It is important that the lift car is prevented
from moving whilst an auto tune is being
conducted. This normally implies that the brake
supply be disconnected.
4. Ensure that no fault condition is present.
Change Parameter
#F27 to F10
Change Parameter
#F27 to D03
Change Parameter
#F27 to D03
Change Parameter
#F27 to L25
