TVC Ethos Two - Appendix A2: Devices Needed for Initial Site Installation - Lift controller using the Limax3 CP

Page 83 of 102
TVL 351
ISSUE 15
Appendix A2: Devices Needed for Initial Site Installation -
Lift controller using the Limax3CP.
Fit and wire the following external devices to the controller terminals to allow the system to operate
under “Inspection Control” for initial site installation. Additionally set “Hoist Mode” in the MMI checklist
so door limits and car network events are ignored.
If in doubt, please contact the factory.
[#] These devices are optional features and may not be fitted on all control panels.
Refer to the site-specific drawings for further details.
External Device Connected between
controller terminals
Top & Bottom Final Limits #
MSA - FL
Limax3CP (OC contact) FL - OTL
Safety Gear Switch OTL - SGS
Overspeed Governor
#
SGS – OS
Buffer Switch OS – BS
Auxiliary Pit Stop Switch # BS - APS
Pit Inspection Control Stop Switch APS – PCS
Pit Stop Switch PCS - PSP
OSG Pit Pulley Weight Switch # PSP - PWS
Limax3CP Tape Presence Switch PWS - TPS
Machine Room Stop Switch TPS – MSP
Cartop Stop Switch STP1 - STP
Cartop Inspection Control Stop Switch STP – CTS
Cartop Inspection Control Switch CTS – TTRX
Cartop Inspection Control Run Command
(Make this switch to run Up or Down) PR – CTP
Cartop Inspection Control Run Command UP
(Make this switch to run Up) CTP – CTU
Cartop Inspection Control Run Command DN
(Make this switch to run Down) CTP – CTD
Pit Inspection Control Switch TTRX – TTX
Inspection UP Limit #
TU - TUP
Inspection Down Limit #
TD - TDN
Car Gate Contact G1 – CG
Landing Gate Contacts CG – GL
Overspeed Governor Anti-Creep Switch # BC1 – BC2
Overspeed Governor Anti-Creep Switch # BC3 – BC4
Motor Encoder # Refer to drawings
Electronic Safety Gear # B24V - SGC
Fit the following panel link – MSP to STP1 if the Pit Door Access Switch and Pit Door Access Reset switch are not
fitted. Ensure the link is removed once the switches are fitted.
