Appendix A1: Devices Needed for Initial Site Installation.
Fit and wire the following external devices to the controller terminals to allow the system to
operate under “Inspection Control” for initial site installation. Additionally set “Hoist Mode” in the
MMI checklist so door limits and car network events are ignored.
If in doubt please contact the factory.
[#] These devices are optional features and may not be fitted on all control panels.
Refer to the site-specific drawings for further details.
External Device
Connected between
controller terminals
Top & Bottom Final Limits MSA - OTL
Safety Gear Switch OTL - SGS
Overspeed Governor SGS – OS
Buffer Switch OS – BS
Pit Stop Switch & Pit Pulley Weight Switch BS – PSP
Machine Room Stop Switch PSP – MSP
Cartop Inspection Stop Switch STP – CTS
Cartop Inspection Control Switch CTS – TTRX
Cartop Inspection Control Run Command UP/DN PR – CTP
Cartop Inspection Control Run Command UP (Make this switch to run Up) CTP – CTU
Cartop Inspection Control Run Command DN (Make this switch to run Down) CTP – CTD
Pit Inspection Control Switch TTRX – TTX
Test UP Limit TU - TUP
Landing Gate Contacts CG – GL
Up Terminal Limit UP – UL
Down Terminal Limit DN – DL
Overspeed Governor Anti-creep Switch # BC1 – BC2
Overspeed Governor Anti-creep Switch # BC3 – BC4
Top Floor Reset Switch MS – TFR
Bottom Floor Reset Switch MS – BFR
Motor Encoder # Refer to drawings
Car Gate Contact +24 – CGX
Pit Access Reset Keyswitch B24V – PRST
Pit Door Access Switch PRST – PDA
HW02 Handwind Switch # MS1 – MS2
