Page 8 of 102
TVL 351
ISSUE 15
2.5. Main Controller Specification
System Supply: 400V a.c. + 10% - 15% 50 Hz. Note: Other voltages available - consult factory.
Main Processor Specification
Supply: 24V d.c. / 0.5A (12W)
Low power shut down voltage: 20V d.c.
Max Voltage on 110V inputs: 120V
Max Voltage on 24V inputs: 30V
Max Voltage on outputs: 120V
Lift + MMI CPU Board: 32bit ARM CPUs with 4Mb Byte Flash, 24Mb RAM.
Features:
3 to 5 CAN Ports
2 to 3 RS232 Ports
2 to 3 RS485 Ports
Ethernet 10/100M
USB
5-24V Incremental Encoder Interface
Digital and Analogue Speed Pattern
7" TFT touch screen (800x480)
Mono audio.
2.6. Environment
Storage Temperature: -10 ºC to +60 ºC
Operating Temperature:
0 ºC to +40 ºC Note: The ambient temperature surrounding the
controller cabinet must be between 0 ºC and 40 ºC.
Humidity Operating Range: 0 - 90% relative humidity (non-condensing)
IP Rating IP2X Protect against dust, moisture and water ingress.
