TVLogic LEM-250A - Menu Operations: GPI Settings; GPI Pin Assignment and Functions

18 FHD OLED Reference Monitor
● This product provides a REMOTE
CONTROL mode. The user may connect
RJ-45 jack to the REMOTE terminal on the
rear of the unit and designate a function
for each pin.
● The default settings are as follows:
PIN 1 : ANALOG CHANNEL
PIN 2 : SDI-A CHANNEL
PIN 3 : SDI-B CHANNEL
PIN 4 : PBP CHANNEL
PIN 5 : TALLY R
PIN 6 : TALLY G
PIN 7 is POWER ON/OFF use only, PIN 8 is GND
- Use the ENTER button and UP/DOWN button
to set the desired function.
LEM-250A
SDI A
[5] GPI
5. Menu Operations
PAGE I >> PAGE II
GPI 1
GPI 2
GPI 3
GPI 4
GPI 5
GPI 6
GPI 7
GPI 8
ANALOG CHANNEL
SDI-A CH A N N EL
SDI-B CH A NNEL
PBP CHANNEL
TALLY R
TALLY G
POWER ON
GND
REM
O
TE (
R
J
-45
)
1:
P
in1
2
:
P
in2
3:
P
i
n
3
4:
P
in4
5: P
i
n5
6:
P
i
n
6
7:
P
in7
8
:
G
ND
1
8
Menu
Classi-
cation
Settable Values
PIN
1~6
NONE,
ANALOG CHANNEL,
SDI-A CHANNEL,
SDI-B CHANNEL,
PBP CHANNEL,
TALLY R,
TALLY G,
UNDER SCAN,
1:1 SCAN, ASPECT,
H/V DELAY,
BLUE ONLY,
MONO,
16:9 MARKER,
4:3 MARKER,
4:3 ON AIR MARKER,
15:9 MARKER,
14:9 MARKER,
13:9 MARKER,
1.85:1 MARKER,
2.35:1 MARKER,
1.85:1&4:3 MARKER,
CENTER MARKER,
SAFETY AREA 80%,
SAFETY AREA 85%,
SAFETY AREA 88%,
SAFETY AREA 90%,
SAFETY AREA 93%,
SAFETY AREA 100%,
708,
608(LINE21),
608(ANC),
OP47,
OP42,
TELETEXT PAGE 801,
TELETEXT PAGE 888,
TELETEXT PAGE 889
PIN 7
POWER ON/OFF CONTROL
PIN 8
GND
