3DS/LRDIMM/LRDIMM 3DS 3200
Capacity
Up to 4,096GB RDIMM/LRDIMM
Memory channel
8 Channels per CPU
Memory voltage
1.2V
Expansion Slots
PCI-E
(2) PCI-E Gen4 x16 slots (FH,10.5"L),
(1) PCI-E Gen4 x8 slot (FH, HL),
(2) PCI-E Gen4 x16 (HH, HL) slots
Pre-install TYAN
Riser Card
(PCI-E Gen4)
(1) M8252T75-L24-1F riser card for
(1) FH/10.5”L PCI-E Gen4 x16 slot
(left), (1) M8252T75-R24-2F riser
card for (1) FH/10.5”L PCI-E Gen4
x16 +
(1) FH/HL PCI-E Gen4 x8 slots (right),
(1) M8252T75-L16-1L riser card for
(1) HH/HL PCI-E Gen4 x16 slot (left),
(1) M8252T75-R16-1L riser card for
(1) HH/HL PCI-E Gen4 x16 slot (right)
Others
(1) PCI-E Gen4 x16 OCP 3.0 slot
LAN
Q'ty / Port
(2) 10GbE ports,
(1) GbE port dedicated for IPMI
Controller
Intel X550-AT2
PHY
Realtek RTL8211E
Storage
SATA
Connector
(2) SFF-8654 connectors for (12)
front SATA
Controller
Direct from AMD EPYC CPU
Speed
6Gb/s
RAID
N/A
NVMe
Connector
(U.2)
(2) SFF-8654 connectors for (4)
front NVMe
Connector
(M.2)
(2) 22110/2280 (by PCI-E Gen3
interface)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
I/O Ports
USB
(2) USB3.1 Gen1 ports (@ front),
(2) USB3.1 Gen1 ports (@ rear)
COM
(2) headers (COM1, COM2)
VGA
(1) D-Sub 15-pin port
RJ-45
(2) 10GbE ports, (1) GbE dedicated
