2.1.4 Installing Hard Drives
The TS75-B8252 supports twelve 3.5”/2.5” hot-swap HDD/SSDs.
Installing 3.5” Hot-Swap Hard Drives
Follow these instructions to install a 3.5” HDD.
Warning!!! Always install the hard disk drive to the chassis after the chassis has
been secured on the rack.
1. Press the locking lever latch and pull the locking lever open.
2. Slide the HDD tray out.
