1.5 About the Product
The following views show you the product.
1.5.1 System Front View
M1718T65-FPB Front Panel Board/ M1717T65-USB USB Board
1
LAN1 LED
7
ID Button
2
LAN2 LED
8
Power Button with green LED
3
ID LED
9
USB 3.1 Port
4
Warning LED
10
USB 3.1 Port
5
HDD LED
11
3.5” /2.5” SSD/HDD/NVMe bays
6
RESET Button
