2.1.3 Installing the Memory
Follow these instructions to install the memory modules onto the motherboard.
1. Press the memory slot locking levers in the direction of the arrows as shown in
the following illustration.
2. Align the memory module with the slot. When inserted properly, the memory slot
locking levers lock automatically onto the indentations at the ends of the module.
Follow the recommended memory population table to install the other memory
modules.
