Appendix II: Cable Connection Tables
1. SlimSAS 8I Cable
B8252T75V8E4HR-2T SKU
Front Backplane (BP) Board to S8252MB
Cable
HDD BP 1
M1297T65-BP12E-12
Connect to
S8252GM2NE-2T/MB
SlimSAS 8I to SlimSAS 8I
SLIMSAS01

SLIMSAS1
SlimSAS 8I to SlimSAS 8I
SLIMSAS23

SLIMSAS2
SlimSAS 8I to Mini SAS HD
SATA 0-3

SLIMSAS J12
SATA 4-7

SlimSAS 8I to Mini SAS HD
SATA 7-11

SLIMSAS J56
Not connected

Power Cable
PW1
PE_PW4
Power Cable
PW2
PE_PW3
HDR 7P Cable
HDR1

J20
B8252T75V12HR-2T SKU
Front Backplane (BP) Board to S8252MB
Cable
HDD BP 1
M1297T65-BP12E-12
Connect to
S8252GM2NE-2T/MB
SlimSAS 8I to Mini SAS HD
SATA 0-3

SLIMSAS J12
SATA 4-7

SlimSAS 8I to Mini SAS HD
SATA 7-11

SLIMSAS J56
Not connected

Power Cable
PW1
PE_PW4
Power Cable
PW2
PE_PW3
HDR 7P Cable
HDR1

J20
2. Front Panel Control Cable
Front Panel
M1718T65-FPB
Connect to
S8252GM2NE-2T/MB
J4

FPIO_2
3. Front Panel USB Cable
Front Panel
M1717T65-USB
Connect to
S8252GM2NE-2T/MB
J3

USB3_FPIO1
