Memory channel
8 Channels per CPU
Memory voltage
1.2V
Expansion Slots
PCI-E
(1) PCI-E Gen4 x8 slot (FH, HL),
(4) PCI-E Gen4 x16 (HH, HL) slots,
(4) PCI-E Gen4 x8 (FH, 10.5”L)
Pre-install TYAN
Riser Card
(PCI-E Gen4)
(1) M8252T75-L24-2F riser card for
(2) FH/10.5”L PCI-E Gen4 x8 slots (left),
(1) M8252T75-R24-3F riser card for
(2) FH/10.5”L PCI-E Gen4 x8 +
(1) FH/HL PCI-E Gen4 x8 slots(right),
(1) M8252T75-L16-2L riser card for
(2) HH/HL PCI-E Gen4 x8 slots (left),
(1) M8252T75-R16-2L riser card for
(2) HH/HL PCI-E Gen4 x8 slots (right)
Others
(1) PCI-E Gen4 x16 OCP 3.0 slot
LAN
Q'ty / Port
(2) 10GbE ports, (1) GbE port
dedicated for IPMI
Controller
Intel X550-AT2
PHY
Realtek RTL8211E
Storage
SATA
Connector
(2) SFF-8654 connectors for
(12) front SATA
Controller
Direct from AMD EPYC CPU
Speed
6Gb/s
RAID
N/A
NVMe
Connector (U.2)
(2) SFF-8654 connectors for
(4) front NVMe
Connector (M.2)
(2) 22110/2280(by PCI-E Gen3
interface)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
I/O Ports
USB
(2) USB3.1 Gen1 ports (@ front),
(2) USB3.1 Gen1 ports (@ rear)
COM
(2) headers (COM1, COM2)
VGA
(1) D-Sub 15-pin port
RJ-45
(2) 10GbE ports,
(1) GbE dedicated for IPMI
