27
Rear I/O: Onboard LAN LED Color Definition
The three (3) onboard Ethernet ports have green and amber LEDs to indicate LAN
status. The chart below illustrates the different LED states.
10Gbps LAN Port
10/100/1000 Mbps LAN Link/Activity LED Scheme
Left LED
(Link/Activity)
Right LED
(Speed)
No Link
OFF
OFF
100 Mbps
Link
Solid Green
Solid Green
Active
Blinking Green
Solid Green
1000 Mbps
Link
Solid Green
Solid Amber
Active
Blinking Green
Solid Amber
(10Gbps)
Link
Solid Amber
Solid Amber
Active
Solid Amber
Solid Amber
1Gbps LAN Port
10/100/1000 Mbps LAN Link/Activity LED Scheme
Left LED
Right LED
10 Mbps
Link
Green
Off
Active
Blinking Green
Off
100 Mbps
Link
Green
Green
Active
Blinking Green
Green
1000
Mbps(1Gps)
Link
Green
Amber
Active
Blinking Green
Amber
No Link
Off
Off
NOTE: “Left” and “Right” are viewed from the rear panel.
