Detach inner rail from standoff
1. Loose screw both sides of the server.
2. Pull the latch upward and remove the keyhole from standoff and slide inner
rail forward to remove inner rail.
Fix the Outer rail/bracket assembly to the frame
Please according to the bracket type, and refer to the install/detach instruction.
1. Secure the outer rails to the rack on each side.
