4 Starting the 850EMT
4.1 Logging On
How to log on to the 850EMT
1 In the PIN Entry screen, enter the 4-digit PIN 7240 by
using the numeric keypad as shown in Figure 6 and
press Enter.
2 If the PIN is correct, the message PIN ACCEPTED is
displayed on the screen. The user will remain logged
in until the 850EMT is turned off.
The PIN Entry screen is as shown in Figure 6.
Fig. 5: 850EMT Start-up Screen
Fig. 6: PIN Entry Screen
1 - Enter PIN Field
2 - Enter key
Invalid PIN
If the PIN entered is incorrect, the message
INVALID PIN is displayed on the screen.
1
2
The screen shown in Figure 5 appears for about 3
seconds after the power is turned on
(refer to Figure 1 #2).
