TYM ET350 ECONO - Page 111

103
No. Code Name 350 Qty
1
2
3
4
5
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
250.36.011-2
25.21.111
GB93-87
GB5782-86
GB898-88
GB5781-86
GB93-87
250.36.125
250.36.129
GB9877.1-88
GB5782-86
GB5782-86
25.21.141
25.21.142
GB98-87
GB5781-86
250.36.155
250.36.154
GB93-87
GB5781-86
GB827-86
ZBT32001.5-87
25.21.140
Mid-connecting case assy
Paper gasket, intermediate housing
Washer12
Bolt M12 X 60
Stud AM 12 X 200
Bolt M 10 X 30
Washer10
Support, release bearing seat
Paper gasket, release bearing seat
Cased seal 42 X 62 X 12
Bolt M 12 X 110
Bolt M 12 X 120
Cover
Paper gasket cover
Washer 8
Bolt M 10 X 20
Gasket, upper cover
Upper cover
Washer 8
Bolt M 6 X 15
Rivet 2 X 5
Tractor nameplate
Plug II – Z1/2”
Paper gasket, intermediate housing to
transmission housing
1
1
13
3
3
4
6
1
1
1
2
2
1
1
6
2
1
1
9
6
4
1
2
1
4. INTERMEDIATE HOSE ASSY
