59
CHAPTER 8 APPENDICES
8.1 Tightening Torque of important Bolts and Nuts
Table 8-1 Tightening torque of important bolts and nuts
Parts to be connected Tightening torque, (kg m)
Cylinder head and cylinder block 12~14
Connecting rod cap and connecting rod 10~12
Cover of main bearing and cylinder block 14~16
Flywheel and crankshaft 10~12
Bracket and engine 9~12
Front bush of 2nd shaft and transmission housing 4~6
Inner bearing cover of drive shaft and final drive housing 4~5
Intermediate housing and flywheel housing 3.5~5
Intermediate housing and transmission housing 6~8
Rear axle sleeve and transmission housing 6~8
Rear axle sleeve and final drive housing 6~8
Front axle sleeve and front axle arm 6~8
Lifter housing and transmission housing 2~3
Steering-gear case and intermediate housing 2~3
Front wheel spoke and front wheel hub 12~14
Rear wheel spoke and drive shaft 12~14
Rear wheel spoke and rear wheel rim 7~9
Ballast weight on rear wheels 3.5~5
