1
CHAPTER 1. MAIN SPECIFICATIONS OF TRACTOR
General specifications
Tractor Model ET 350 ECONO
Type Frameless, 4WD tractor
Rated draft(kn/kgf) 9.14/932
Dry weight(kg 1450
Min. operation weight(kg) 1565
Wheel tread(mm)
Front wheel 1160
Rear wheel 1100~1400
Radius of turning circle(m)
With one side braked 3.4
Without braking 3.8
Min,ground clearance(mm) 290
Overall dimensions(mm)
Length 3070
Width 1493
Height(to the top of steering wheel) 1540
Theoretical travel speed of tractor(km/h)
1st gear 1.74
2nd gear 2.20
3rd gear 3.58
4th gear 5.68
5th gear 6.83
6th gear 8.63
7th gear 14.04
8th gear 22.27
1st rev. Gear 1.63
2nd rev.Gear 6.38
Engine
Model TY395E
Type Vertical,in-line,water-cooled,four-stroke
Number of cylinders 3
Bore X Stroke(mm) 95/105
