Tractor Model ET 350 ECONO
Rated speed(r/min) 230
Rated output(kW/hp) 25.7/35
Max.torque(Nm)
≥122.7
Speed at max. torque(r/min)
≤ 1725
Fuel consumption(g/kWh) 245
Oil consumption(g/kWh)
≤ 2.04
Method of lubrication Pressure and splash combined
Method of cooling Closed and forced water circulation
Method of starting Electric starting
Rotating direction(as viewed from the fan) Clockwise
Transmission system
Clutch Dry single-disk constant engagement or
Double Belleville spring interlock controlled
Gear box Straight gear (4+1) X 2
Central drive Spiral bevel gear
Differential Two bevel planetary-gear, closed type
Final drive External exterior engagement, straight gear type
Brake Pedal, mechanical-actuated, closed shoe-type
Running and steering system
Type of drive Rear-wheel drive
Type of front axle Tube with adjustable wheel tread
Specification of tire
Front wheel 6.50-16
Rear wheel 11.2-24
Tire pressure(MPa)
Front wheel 0.23~0.25
Rear wheel 0.10~0.12
Toe-in(mm) 3~11
Camber, front wheel
2°
Kingpin inclination
10°
Kingpin caster 0
Steering gear Worm and roller or BZZ1-80 fully-hydraulic
Ackerman steering Backward of axle
Working facilities
Hydraulic lift
Type Partial separated units
Working depth control Draft and position control combined
