CHAPTER 3. OILING AND RUNNING – IN PROCESS
3.1 Oiling and Fueling of Tractor
1. Oiling and Fueling Points of the Tractor
The oiling and fueling points of the tractor & Specification of fuel and lubricants are shown in Table 3-1
Table 3-1 Specifications of fuels and lubricants for tractor
2. Instructions on the Use of Fuel
(1) Fuel must be settled for at least 48 hours before used.
(2) Fuel must be carefully filtered when it is handled
(3) It is not permitted to wipe any containers or fuel line connections with felts, cotton waste or used cloth.
At ambient temperature
above 0°C
At ambient temperature
below 0°C
Fuel tank No.0 light diesel fuel(GB252-87) No.10 light diesel fuel(GB252-87)
Engine oil sump,speed governor
No.HC-11 diesel engine oil
(SY1152-77)
Recommended foreign brand :
SAE 30 Oil or equivalent
No.HC-8 diesel engine oil
(SY1152-77)
Recommended foreign brand :
SAE 15W/30 Oil or equivalent
Hydraulic lift, oil tank
No.HC-11 diesel engine oil
(SY1152-77)
Recommended foreign brand :
SAE 30 Oil or equivalent
No.HC-8 diesel engine oil
(SY1152-77)
Recommended foreign brand :
SAE 15W/30 Oil or equivalent
Final drive, front driving axle
90-GL-3 gear oil or gear oil
SAE 80
85W-90-GL-3 gear oil or gear oil
SAE 80
2 grease nipples in clutch bearings
15 grease nipples, including 1 nipple
in each of water pump bearing, left
and right steering arm, two front
driving shafts and front/rear bush
seats ; 2 nipples in each of axle
bushing of clutch pedal &
interme diate housing, 4nipples in
connection rod ends
Brand of fuel and lubricants
ZG-2 calcium based lubrication grease (GB491-65) Recommended
foreign brand : AA2, B2-MOBIL
ZN-sodium based lubrication grease (GB492-87) Recommended
foreign brand : BRB3-MOBIL
Fueling and Oiling points
