TYM ET350 ECONO - Page 155

148
22. TRANSFER CASE ASSY
No. Code Name 350 QTY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
GB876.1-86
254.42.102
254.42.103
254.42.101
304.42.107
254.42.105
254.42.104
GB308-89
GB1235-76
254.42.109
254.42.110
GB9877.1-88
GB276-89
254.42.108
254.42.129
254.42.116
304.42.112
GB6170-86
GB5781-86
GB119-86
254.42.111
254.42.113
GB309-84
254.42.115
304.42.114
25.37.139
254.42.119
Snap ring 25
Thrust bush
Rubber cover
Ball connection sleeve
Transmission shaft
Washer
Spring
Steel ball ∮8(11/32”)
O-ring 55 X 3.1
Front cover
Gasket, front cover
Oil seal PD 30 X 45 X 10
Bearing 106
Transfer case PTO shaft
Transfer case body
Gasket, transfer case
Sliding gear
Nut M8
Screw M8 X 25
Pin D8 X 16
Intermediate gear shaft
Snap ring
Needle 3 X 24
Needle snap ring
Intermediate gear
Shift block PTO
Release fork shaft
2
2
2
2
1
1
1
12(1)
1
1
1
2
2
1
1
1
1
2
1
2
1
2
58
1
1
1
1
