TYM ET350 ECONO - Page 167

160
26. FENDER, FLOOR BOARD & TOOL BOX
No. Code Name 350 QTY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
GB5781-86
GB93-87
254.47.043-1
GB6170-86
GB93-87
GB97.1-86
GB5781-86
GB93-87
GB5781-86
GB6170-86
GB97.1-86
25.47.194
GB6170-86
GB93-87
GB5781-8616
25.47.021-3
25.47.165
GB5781-86
25.49.021-1
25.50.103
25.49.011
25.47.022-3
GB5781-86
25.47.042-1
25.47.023-A
25.47.024-A
Bolt M10 X 25
Washer 10
Pedal assy, L.H
Bolt M8
Washer 8
Washer 8
Bolt M8 X 20
Washer 12
Bolt M12 X 25
Bolt 12
Washer 12
Handle
Bolt M6
Washer 6
Bolt M8 X 25
Left fender assy
Catch, starter handle
Bolt M6 X 16
Starter handle assy
Rubber washer
Toolbox assy
Right fender assy
Bolt M12 X 30
Pedal assy, R.H.
Left fender support welding assy 1
Right fender support welding assy 1
4
1
1
6
6
4
4
12
18
4
18
2
6
6
2
2
1
3
6
1
2
1
1
2
1
1
