Table 5-1 Detailed Component List of Double-action Clutch
No. Code Description Qty
1 25.21.111 Paper gasket, bridge casing 1
2 GB898-88 Stud AM 12X150 2
3 GB5782-86 Bolt M 12X75 4
4 GB898-88 Stud AM 12X70 1
5 GB898-87 Spring washer 12 10
6 250.21.111* Adjusting screw 3
7 250.21.120* Bush 3
8 25.21.229 Plug 1
9 250.21.104* Bellevile spring 2
10 250.21.128* Release lever 3
11 GB5782-86 Bolt M 12X95 1
12 25.21.013 Drive plate assembly, clutch 1
13 GB278-89 Ball bearing 1
14 250.36.102* Shaft, PTO clutch 1
15 25.21.230 Spacing sleeve 1
16 250.36.101* Shaft, master clutch 1
17 250.21.011* Driven plate assembly, master clutch 1
18 250.21.105* Pressure plate, PTO clutch 1
19 250.21.107* Pressure plate, master clutch 1
20 250.21.109* Clutch cover 1
21 250.21.101* Pull-rod 3
22 250.21.106* Fixed pressure plate, PTO shaft 1
23 GB898-88 Stud AM12X170 2
24 250.21.102* Pressure spring 3
25 GB97.1-85 Flat washer 10 7
26 GB6173-86 Nut fine M 10X1 6
27 GB6173-86 Nut fine M 10X1 6
28 SF-1* Bush 220 2
29 * Release bearing 9688213 1
