TYM ET350 ECONO - Page 41

34
Signal No. Code Description Qty
60 250.36.131* Rubber pad, cover 1
61 250.36.128* Watch window cover 1
62 GB93-87 Spring washer 10 12
63 GB5781-86 Bolt M10X20 2
64 GB5782-86 Bolt M10X70 6
65 GB882-86 Pin shaft B10X45 3
66 GB9877.1-88 Metal-cased oil seal 42X62X12 1
67 GB119-86 Pin D8X16 2
68 GB5781-86 Bolt M10X30 4
69 250.21.113* Return spring, release bearing seat 2
70 250.21.131* Release bearing seat 1
71 GB876-86 Spring pin 10X40 2
72 250.21.117 Release fork rod, clutch 1
73 25.21.115 Bush 1
74 250.21.112* Release fork 1
75 250.36.154* Upper cover 1
76 250.36.155* Gasket, upper cover 1
77 250.21.118* Spherical nut 3
78 GB5781-86 Bolt M6X15 6
79 GB93-87 Spring washer 6 6
80 250.21.108* Return spring 3
81 GB6170-86 Nut N12 5
